● 高灵敏度适合低照度应用
● high sensitivity for low light applications
● 低电压适合嵌入式应用
● low voltage suitable for embedded applications
● 标准的SCCB接口，兼容I2C接口
The standard SCCB interface, compatible with I2C interface
●RawRGB,RGB(GRB4:2:2,RGB565/555/444),YUV(4:2:2)和YCbCr(4:2:2)输出格式
RawRGB, RGB (GRB4:2:2, RGB565/555/444), YUV (4:2:2) and YCbCr (4:2:2) output format
● 支持VGA,CIF,和从CIF到40x30的各种尺寸
● support VGA, CIF, and from CIF to a variety of size 40x30
●VarioPixel子采样方式
● VarioPixel sub sampling mode
● 自动影响控制功能包括：自动曝光控制、自动增益控制、自动白平衡，自动消除灯光条纹、自动黑电平校准.图像质量控制包括色饱和度、色相、伽玛、锐度ANTI_BLOOM
Automatic control functions include: automatic exposure control, automatic gain control, auto white balance, automatic elimination of light stripe, automatic black level calibration. Image quality control includes color saturation, sharpness, hue, Gama ANTI_BLOOM
●ISP具有消除噪声和坏点补偿功能
● ISP can eliminate the noise and error compensation function
● 支持图像缩放
● support image scaling
● 镜头失光补偿
● lens light loss compensation
●50/60Hz自动检测
● 50/60Hz automatic detection
● 饱和度自动调节（UV调整）
● saturation automatic adjustment (UV)
● 边缘增强自动调节
● edge enhancement automatic regulation
● 降噪自动调节
The noise automatic regulation
关键参数:
Key parameters:
感光阵列640X480
Photosensitive array 640X480
IO电压2.5V to 3.0V (内部LDO给核供电1.8V)
IO voltage 2.5V to 3.0V (internal LDO to nuclear power 1.8V)
功耗工作60mW/15fpsVGAYUV
The power consumption of 60mW/15fpsVGAYUV
休眠<20μA
The dormancy of <20 μ
温度操作-30℃到70℃
Operating temperature of -30 ℃ to 70 ℃
稳定工作0℃到50℃
Stability of 0 ℃ to 50 ℃
输出格式（8位）? YUV/YCbCr4:2:2 RGB565/555/444 GRB4:2:2 Raw RGB Data
The output format (8 bit) YUV/YCbCr4:2:2 RGB565/555/444 GRB4:2:2 Raw RGB Data?
光学尺寸1/6"
Optical size 1/6"
视场角25°
A view angle of 25 degrees
最大贞率30fps VGA
The biggest cheer rate 30fps VGA
灵敏度1.3V/(Lux-sec)
The sensitivity of 1.3V/ (Lux-sec)
信噪比46 dB
Signal to noise ratio of 46 dB
动态范围52 dB
Dynamic range of 52 dB
浏览模式逐行
Browse mode line by line
电子曝光1行到510行
Electronic exposure of 1 to 510 lines
像素面积3.6μm x 3.6μm
The pixel area of 3.6 μ m x 3.6 μ
暗电流12 mV/s at 60℃
The dark current of 12 mV/s at at 60 ℃
