jlink V8 emulator / j-link ARM9 STM32 ARM emulator + multifunction adapter plate
Introduction:
( 1 ) Use JLINK V8 original firmware, supports automatic upgrades.
( 2 ) complete reference circuit schematic of the original JLINK V8 .
( 3 ) strictly in accordance with the original JLINK V8 circuit layout.
( 4 ) strictly in accordance with the original JLINK V8 line traces.
( 5 ) the use of large -capacity power circuit as a non-polar capacitor filter, the same as with the original JLINK V8 .
(6) USB socket housing through a resistor and capacitor in parallel with the ground , the same as with the original JLINK V8 .
( 7 ) the use of a red and green LED indicates the internal work status ( green light indicates working , the red light indicates the reset state ) , the same as with the original JLINK V8 .
( 8 ) output circuit using two Philips 74ALVC164245, SWD and JTAG support 1.2-5V voltage , the same as with the original JLINK V8 .
( 9 ) dual protection : JLinkUSB mouth esd protection ic full protection ! Using 500 mA resettable fuse to protect our USB ports, full protection !
( 10 ) shop JLink uses 1.5A high current transistor 8550 , to ensure that power on command output 400ma current ! Your product can be powered directly from JLINK simulation , very convenient !
( 11 ) This product is designed to target the original JLINK V8 , stable performance, has been at or near the original JLINK V8 's performance .
( 12 ) In comparison tests with V7 , V8 can clearly feel the erase and programming faster and more stable.
( 13 ) machine chip production , strict quality inspection , so that product quality 100% qualified , ease of use .
J-Link support for ARM cores :
* ARM7TDMI (Rev 1)
* ARM7TDMI (Rev 3)
* ARM7TDMI-S (Rev 4)
* ARM720T
* ARM920T
* ARM926EJ-S
* ARM946E-S
* ARM966E-S
* ARM1176JZF-S
* Cortex-M0
* Cortex-M3
* Cortex-M4
* Cortex-A8
* Cortex-A9
Two J-Link V8 LED status lights
J-Link V8 green light indicates working status .
J-Link V8 red light indicates the reset state.
Shipping list
1x J-Link V8 emulator pod
1x USB cable copper shield
1x standard 20PIN 2.54mm pitch cable emulation
1x multifunction adapter plate
1x data CD
